DESATA-ECS

Two eSATA 7pin receptacle to SATA 7pin plug signal extension cable with SCSI 1 connector Form Factor Bracket

DESATA-ECS
Introduction
DESATA-ECS is two eSATA 7pin receptacle to SATA 7pin plug signal extension cable with SCSI 1 50pin
low density Cetronics Connector form factor bracket (BR-00224).
Direct attach the 7 positions SATA connector to the SATA bridge controller and fasten the SCSI 1 50pin low density Cetronics Connector form factor bracket to the SCSI case.

Technical Specification
  • Signal Female Type eSATA Connector to 7 positions Serial ATA Connector
  • Serial ATA 7-positions signal cable
  • w/ SCSI 1 50pin low density Cetronics Connector form factor bracket (BR-00224)
Part No. Length
2*CB-00322+BR-00224 45CM
2*CB-00323+BR-00224 25CM
2*CB-00324+BR-00224 10CM

Applications
